| 1.Ordering Code : | |||||
| SPC | 8 | ‐ | G | 02 | |
| ↑ | ↑ | ↑ | ↑ | ||
| Model | O.D. of tube | Thread type | Thread size | ||
| SPC | 4: Φ4mm | □: PT thread | 01: 1/8" | ||
| SPL | 6: Φ6mm | G: G or BSP | 02: 1/4" | ||
| SPE | 8: Φ8mm | N: NPT | 03: 3/8" | ||
| SPM | 10: Φ10mm | M5: M5x0.8 | 04: 1/2" | ||
| SPV | 12: Φ12mm | M6: M6x1 | 06: 3/4" | ||
| SPY | 14: Φ14mm | 08: 1" | |||
| . | 16: Φ16mm | ||||
| . | Or imperial size | ||||
| 3.Specification: | ||||||
| Item | Parameter | |||||
| Working Medium | Air, Steam, Water, and some other liquid | |||||
| Pressure Range | 0~1.2MPa | |||||
| Negative Range | -100KPa (10Torr) | |||||
| Proof Pressure | 3.0MPa | |||||
| Ambient Temperature | -5~200℃ | |||||
| Material of body | SUS316 or SUS304 | |||||
| Material of sealing | FKM (Viton) | |||||
| Applicable Tube | PU,PE,Nylon(PA),PVC and Teflon Tube | |||||
